How to choose SX1280 LoRa module

SX1280

It is a 2.4GHz band RF chip from Semtech. This chip contains various physical layers and various modulation methods, such as LoRa, FLRC, GFSK. The special modulation and processing method greatly increases the transmission distance of LoRa and FLRC modulation. It is a high-performance IoT wireless transceiver and is compatible with the Bluetooth protocol. Excellent low-power performance, on-chip DC-DC and Time-of-flight make this chip powerful and can be used in smart homes, security systems, location tracking, wireless ranging, wearable devices, smart bracelets and health management, etc. SX1280 supports RSSI, and users can realize in-depth secondary development according to their needs. SX1280 also integrates "time of flight", which is suitable for ranging function.

NiceRF has LoRa modules which using SX1280:

LoRa1280、LoRa1280-TCXO、LoRa1280F27、LoRa1280F27-TCXO

How to choose SX1280 LoRa module

1. Similarities between the four SX1280 LoRa modules

• Operating frequency range：2400～2500MHz
• Sensitivity : -132dBm@LoRa
• Modulation mode: LoRa, FLRC, (G)FSK
• Data transfer rate：476～202 Kbps@LoRa
• Packet communication mode (receiving FiFo 256 bytes)
• Operating temperature range：-40~+85℃

2. Differences between the four SX1280 LoRa modules

That’s all about how to choose sx1280 LoRa module and hope it’s helpful for everyone.
