How to choose the different series of Uart RF modules

Dec . 2021

By sdga:NiceRF Wireless Technology Co., Ltd

Recently, many customers ask us how to choose the right Uart RF modules. What is the difference between LoRa Uart modules and (G)FSK uart rf modules? Below may help you.

Introduction of the different series of Uart RF modules

1. Wireless LoRa Uart module

P/N	Output power	Working frequency band	Range	Power consumption		RX sensitivity	Modulation
P/N	Output power	Working frequency band	Range	Tx current	RX current	RX sensitivity	Modulation
LoRa600PRO	100mW	433/470 /868/915MHz	5Km	<130mA	<15mA	-139dBm	LoRa
LoRa610PRO	100mW	433/470 /868/915MHz	5Km	<130mA	<15mA	-139dBm	LoRa
LoRa611PRO	100mW	433/470 /868/915MHz	5Km	<130mA	<15mA	-139dBm	LoRa
LoRa6100PRO	1W	433/470 /868/915MHz	8Km	<600mA	<16mA	-139dBm	LoRa
LoRa6102PRO	1W	433/470 /868/915MHz	8Km	<600mA	<16mA	-139dBm	LoRa
LoRa6103PRO	500mW/1W	433/470 /868/915MHz	8Km	<600mA	<30mA	-139dBm	LoRa
LoRa6200PRO	2W	433/470MHz	8Km	<500mA	<18mA	-139dBm	LoRa
LoRa6500PRO	5W	433/470MHz	10Km	<1.8A	<18mA	-139dBm	LoRa
LoRaP30PRO	30W	433MHz	25Km	<4A	<23mA	-139dBm	LoRa
LoRa Star series	LoRa Uart module LoRa Star series share the same hardware as LoRaPro series, but different firmware, and add Star network feature

2. (G)FSK Uart RF module

P/N	Output power	Working frequency band	Range	Power consumption			RX sensitivity	Modulation
P/N	Output power	Working frequency band	Range	Tx current		RX current	RX sensitivity	Modulation
SV610	100mW	433/470 /868/915MHz	1400m	95mA	25mA		-121dBm	(G)FSK
SV610PRO	100mW	433/470 /868/915MHz	2000m	95mA	<22mA		-123dBm	FSK
SV611	100mW	433/470 /868/915MHz	1400m	95mA	25mA@TTL level 34mA@485 level 32.7mA@232 level		-121dBm	(G)FSK
SV612	100mW	433/470 /868/915MHz	1400m	95mA	25mA@TTL level 34mA@485 level 32.7mA@232 level		-121dBm	(G)FSK
SV613	100mW	433/470 /868/915MHz	1400m	95mA	26mA		-121dBm	(G)FSK
SV614	100mW	433/470 /868/915MHz	1400m	95mA	33mA		-121dBm	(G)FSK
SV650	500mW	433/470 /868/915MHz	2800m	350mA	25mA@TTL level 34mA@485 level		-121dBm	(G)FSK
SV650-TF	400mW	868MHz	2500m	<320mA	25mA@TTL level 34mA@485 level		-121dBm	(G)FSK
SV651	800mW	433/470 /868/915MHz	2800m	730mA	25mA@TTL level 34mA@485 level 32.7mA@232 level		-121dBm	(G)FSK
SV652	800mW	433/470 /868/915MHz	2800m	750mA	25mA@TTL level 34mA@485 level 32.7mA@232 level		-121dBm	(G)FSK
SV653	800mW	433/470 /868/915MHz	2800m	750mA	26mA		-121dBm	(G)FSK
SV654	800mW	433/470 /868/915MHz	2800m	750mA	32.7mA		-121dBm	(G)FSK
SV6202	2W	433/470MHz	5000m	900mA	25mA@TTL level 34mA@485 level 32.7mA@232 level		-121dBm	(G)FSK
SV6300	3W	433/470MHz	6000m	<600mA	<30mA		-121dBm	(G)FSK
SV6500	5W	433/470MHz	8000m	<1.8A	<30mA		-121dBm	(G)FSK
SV6500PRO	5W	433/470 /868/915MHz	8000m	<2A	<30mA		-121dBm	FSK/4FSK
SV-MESH series	Uart RF module SV-Mesh series share the same hardware as SV series, but different firmware, and add mesh network feature.

Difference between LoRa Uart module and (G)FSK Uart RF modules

P/N	Feature	Max RF data rate	Min RF data Rate	Max payload for one packet	Delay time	AES encryption	Mesh	LBT	Communicate between Lora and (G)FSK
LoRa_Proseries	Mesh+ transparent Uart + router+ AES	17353bps	91bps	227	Refer to datasheet	Yes	Yes	Yes	No
LoRa_Star series	Mesh+ transparent Uart + router+ AES	17353bps	91bps	225	Refer to datasheet	Yes	Yes	Yes	No
SV series	Transparent Uart	115200bps	1.2Kbps	56	Refer to datasheet	No	No	No	No
SV_MESH series	Mesh + Transparent Uart	115200bps	1.2Kbps	56	Refer to datasheet	No	Yes	No	No

Above is the summary, hope to help you. Thanks!
