Application of ASK transmitter module STX883PRO in wireless doorbell

By sdga:NiceRF Wireless Technology Co., Ltd

As the most widely used doorbell in the doorbell market, the wireless doorbell has the advantages that the traditional doorbell does not have. It is smarter and simpler than the traditional doorbell.

Wireless doorbells usually consist of two parts: outdoor unit and indoor unit. The two components of the wireless doorbell form a wireless system, and each part of the system communicates with each other to realize the doorbell alarm function. Next, NiceRF will use our company's ASK transmitter module STX883Pro and ASK receiver module SRX883Pro, which are used in wireless doorbells, to explain the working principle of wireless doorbells.



The working principle of the transmitter (outdoor unit):

Transmit the control signals generated by peripherals such as doorbell buttons through the ASK transmitter module STX883Pro.



The working principle of the receiver (indoor unit):

The superheterodyne receiver module SRX883Pro receives the control signal from the transmitter and broadcasts it through the speaker.

Wireless doorbell receiver

NiceRF application advantages in wireless doorbells

Recommended modules: NiceRF ASK transmitter module STX883Pro and ASK receiver module SRX883Pro

Application of ASK transmitter module STX883PRO and ASK receiver module SRX883PRO in wireless doorbell

Our STX883Pro is a small, ultra-thin, low-harmonic ASK transmitter module that can be certified. The chip design greatly improves the stability of the product. The data port of the module can be directly connected to the MCU to make wireless products R&D and production are more convenient and faster.

SRX883Pro is a ASK receiver module with low latency, fast response and micro power consumption. It can be used with our STX series ASK transmitter module. It has high stability, anti-interference and high cost performance, but also has a super driving force. STX883Pro and SRX883Pro have obtained FCC, CE and other certifications.

NiceRF Wireless Technology Co., Ltd. focuses on various IoT solutions such as wireless doorbell applications, and has high-quality technical support services, a sound production system, and a complete quality assurance system. ODM projects can be customized according to customer needs, welcome to inquire.
