RF3060F27 is a module based on the low-power, long-range wireless transceiver chip that utilizes ChirpIoT™ modulation and demodulation technology, supporting half-duplex wireless communication. This module not only incorporates an advanced TCXO crystal oscillator to ensure high frequency stability, but also features high sensitivity, low power consumption, and ultra-long transmission distance, making it the ideal choice for long-distance transmission and applications with high reliability requirements. Compared to the RF3060, it maintains the same size but offers more than 500mW of power with a 5V supply, doubling the communication range compared to the RF3060. This provides a wider range of options for long-distance transmission and applications requiring high reliability.

Product Advantages

1. Same Small Size, Double the Communication Distance
The RF3060F27 retains the same size as the RF3060 but achieves twice the communication distance through optimized internal circuit design and advanced spread spectrum technology. The maximum transmission distance can reach up to 8-10km.

2.TCXO Crystal Oscillator, Frequency Error Stable at 0.5ppm
The RF3060F27 integrates a TCXO (Temperature Compen sated Crystal Oscillator), ensuring that the frequency error remains stable at 0.5ppm. This greatly reduces communication failures due to frequency shifts, even in environments with significant temperature changes, while maintaining stable communication performance.

3.High Sensitivity, Low Power Consumption Design
The RF3060F27 features an ultra-high sensitivity of -135dBm. While maintaining high performance, it emphasizes low power consumption design. The sleep current is lower than 1uA, and the receive current is only 6mA (in DCDC mode), significantly reducing the device's energy consumption.

4. CAD Function + Spread Spectrum Factor Support
The RF3060F27 supports CAD (Channel Activity Detection) functionality, enabling quick response to channel status changes and reducing power consumption. Additionally, the module supports automatic adjustment of spread spectrum factors (SF) from 5 to 9, intelligently balancing transmission rate and distance according to the actual application scenario, meeting the demands of logistics tracking, industrial control, and other applications.

Product Features

 Frequency Range:433/470/ MHz

 Built-in TCXO, frequency error 1ppm

 Sensitivity：-135dBm @60.5KHz,500pbs

 Maximum output power：> 27dBm @ 5V

 Low receive current: 6mA@DCDC

 Sleep current < 1.0uA

  Data transfer rate: 0.5-59.9Kbps @LoRa

  Supports bandwidth: 125/250/500kHz

  Supports SF factor: 5–9, automatic recognition

  Supports data rates: 4/5, 4/6, 4/7, 4/8

  Supports CAD function

Electrical Characteristics

Applications

 Smart Factory

 Smart Water Management

 Smart Agriculture

  Smart Healthcare

  Smart Community

  Smart Firefighting
