Differences between GPS modules GPS02-UBX, GPS01-TD and GPS01
By sdga:NiceRF Wireless Technology Co., Ltd
GPS02-UBX is a new low-drift multi-satellite positioning and navigation GPS module based on UBLOX's latest generation IC M10 series. So what is the difference between it and our other two GPS modules GPS01-TD and GPS01?
Differences between GPS modules GPS02-UBX, GPS01-TD and GPS01
1. Similarities of the three GPS modules:
● With backup power input interface
● Support for hot start
● Support for power supply to active antenna
● Support A-GNSS assisted positioning
● Support for power-on reset, internallyintegrated low-voltage reset, external reset, software reset
● Operating temperature range: -40～85℃, storage temperature range: -40～125℃
● Positioning accuracy @ open field: level <3m, elevation <4.5m
● External antenna gain: 30dB
● Speed measurement accuracy <0.1m/s
● Time to first fix TTFF: cold start <28s, hot start: 1s, recapture: 1s
2. Differences between the three GPS modules:
| Product model | UBLOX GPS module GPS02-UBX | Mini GPS module GPS01-TD | Mini GPS module GPS01 |
| Support satellite navigation system | BDS/GPS/GLONASS/ Galileo (Choose three of four, BDS and GLONASS cannot be used at the same time.) | BDS/GPS/GLONASS/ Galileo | BDS/GPS/GLONASS |
| Auxiliary Satellite Navigation System | Support SBAS and QZSS | Support SBAS and QZSS | * |
| Operating mode | 1. Support BDS, GPS, GLONASS, Galileo single system work; 2. Support dual system work; 3. Support BDS/GPS/GLNOASS, BDS/GPS/Galileo three systems; | 1. Support BDS, GPS, GLONASS, Galileo single system work; 2. Support dual system work; 3. Support BDS/GPS/GLNOASS, BDS/GPS/Galileo three systems; 4. Support BDS/GPS/Galileo/GLNOASS four system work | 1. Support BDS, GPS, GLONASS single system work; 2. Support BDS/GPS, BDS/GLNOASS, GPS/GLONASS dual system work; |
| Sensitivity | Capture: -148dBm Tracking: -166dBm | Capture: -147dBm Tracking: -163dBm | Capture: -147dBm Tracking: -163dBm |
| Data update rate | Single system: 1～18Hz | Single system: 1～20Hz Dual system: 1～10Hz Three systems: 1～10Hz Four systems: 1～10Hz | Single system: 1Hz Dual system: 1Hz |
| Operating voltage range | VCC：2.7～3.6V V_BCKP：2.5～3.5V | VCC：3～3.5V V_BCKP：2.5～3.5V | VCC：3～3.5V V_BCKP：2.5～3.5V |
| Receive current | <25mA | <35mA | <30mA |
| Sleep current | <35uA | <25uA | <20uA |
| Serial port baud rate | 4800～921600bps | 4800～230400bps | 4800～230400bps |
| Size (L*W*T) | 16.45*14.5*2.3 mm | 10.1*9.9*2 mm | 10.1*9.9*2 mm |
That’s all about the differences between GPS modules GPS02-UBX, GPS01-TD and GPS01 and hope it’s helpful for everyone.
