New: 160mW Low Current Uart LoRa Module LoRa610II Using LLCC68 Chip

In December 2021, NiceRF launch the new product: 160mW Low Current Uart LoRa Module LoRa610II Using LLCC68 Chip.

Introduction of LLCC68 LoRa Module LoRa610II

LoRa610II is a LoRa Uart module launched by NiceRF. Its low current are the main characteristics. The module adopts LLCC68 chip scheme and is designed based on Semtech official standard. Built-in hardware anti-crash self-reset circuit to resist strong external interference signals.

The LoRa610II module is designed for 160mW output power and embedded small size design, which is widely used in wireless remote transmission control industries.

LoRa610II module supports AES128 data encryption method, LBT (Listen Before Talk) function is optional, and node/routing/node+routing is optional in MESH mode.

Features of LLCC68 LoRa Module LoRa610II:

• AES128 data encryption method
• No blind zone without distance limitation with mesh technology
• Frequency band: 433/470/868/915 MHz for option
• Up to 40 communication channels in the same frequency band
• Diversified serial port parameters
• Operating voltage range: 1.8~ 3.7 V
• LBT (Listen Before Talk) function optional
• Node/route/node+route optional in MESH mode
• Built-in hardware reset protection circuit
• LoRa modulation
• TTL interface
• Sensitivity up to -139 dBm
• Maximum output power: 160 mW (+22dBm)
• Operating temperature range: -40 ~ +85 °C

Applications of LLCC68 LoRa Module LoRa610II:

• Remote control
• Remote meter reading
• Industrial data collection
• Home automation telemetry
• Wireless data communication
• Access control system

Pin definition:

Mechanical dimension(Unit: mm)

Please feel free to contact us if any query on this products, and check our website ( www.nicerf.com ) for more information. Welcome to leave your message at: sales@nicerf.com.
